Top or bottom reel-holder for reels up to 600 mm in width.
Universal forming unit adjustable by handwheel.
Longitudinal sealing unit adjustable in height with two pairs of sealing wheels and two flap folding wheels.
Cross sealing unit adjustable in height with 200 mm sealing bars.
Four brushless motorizations driven by a Rockwell Allen Bradley® control: cross sealing jaws stroke longitudinal sealing wheels transport belt through the sealing jaws infeed conveyor
Control panel on the machine frame.
Sealing time adjustable by PLC.
Machine built according to CE standard.
Accessories
Automatic feeding.
UVC lamps for film sterilization.
Gas injection.
Oxygen residual continuous analyzer.
Mechanical bellows.
Labelling systems.
Print-on-film systems.
Wire cutting and film trimming device
