teco cd
The eco cd series thermoregulators are designed to work with water and direct cooling up to 95°C or 120°C.
The temperature of the process water is regulated automatically. A temperature sensor installed inside the unit measures the available actual temperature.
A microprocessor control unit with a membrane keyboard or touch screen compares the measured value with a pre-selected preset value and controls heating or cooling. Trouble-free operation is guaranteed by a comprehensive security system.
As standard, the device is equipped with a large number of functions that can be supplemented with various useful options on request. All relevant interfaces are available for communication with the controllers of processing machines.
Description
Characteristics
Ask question
Compact direct cooling thermostats
• High-precision microcontroller with automatic optimization
• Touch screen (7-inch) for logging in, managing and
monitoring parameters
• Intuitive operating interface with intuitive menu navigation
• Integrated operational and service information
• Measurement, indication and flow tracking
• Saving and resuming operating parameters with a memory card
• Wear-resistant, energy-saving solid-state heating control
• Return water temperature indicator
• Continuous monitoring of operating parameters
• * Optional connection to an external thermocouple (Fe-Cu Ni or Pt 100)
• Optional front panel interface (analog 0 - 10 V,
0/4 - 20 mA; serial RS 232, RS 422, RS 485, RTU; Profibus; Profinet)
• Water-resistant electrical equipment
• Three meter long power cable with CEE 4 connector
• Housing and cover RAL 7012 grey
• Side panels: RAL 2004 orange
Product question
Write your question in the form and indicate your contact. The manager will contact you shortly.
