teco wi

Along with various power indicators that a modern thermostat should have, the teco wi range is characterized by absolute reliability, high adjustment accuracy, ease of maintenance and an optimal combination of price and quality.

This series of thermostats was developed in the process of close cooperation with our customers, characterized by a modular design. A variety of combinations of heating and cooling elements allow the thermostat to be used in the widest range.

For particularly demanding customers, there are a number of useful options available. The teco thermostats of the wi model range are presented in various designs as water with indirect cooling for open use at temperatures up to 95 °C, and for use in closed systems at temperatures up to 160 °C.

A high–precision GWK microcontroller with a touch color display is standard equipment for all thermostats.

Description

Characteristics

Ask question

Powerful thermostats in modular design

• High-precision microcontroller with automatic optimization
• Display with simultaneous display of set and current parameters
• Measurement, indication and flow tracking
• integrated operational and service information
• Saving and resuming operating parameters with a memory card
• Wear-resistant, energy-saving solid-state heating control
• Return water temperature indicator
• Continuous monitoring of operating parameters
• * Optional connection to an external thermocouple (Fe Cu Ni or Pt 100)
• * Optional front panel interfaces (analog 0 - 10 V, 0/4 - 20 mA; serial RS 232, RS 422, RS RS 485, RTU; Profibus and Varan-Bus)
• * Side walls: RAL 2004 orange
• Front panel and housing: RAL 7035 light grey
