Rapid ThermoPRO

Rapid ThermoPro is optimized for in-line crushing of skeletal waste. The difference between profit and loss in the thermoforming industry often depends on how efficiently you can recycle.

  • "Open access" design — for quick and easy access to the cutting chamber of the granulator for cleaning/maintenance.
  • 3 types of loop control – fully integrated, external or stand-alone control loop for integrated integration with thermoforming machine.
  • The lowest noise level on the market is with a full soundproof casing of less than 80 dB (A), depending on the material and application.
  • 3 widths are available: 600, 900 and 1200 mm with a capacity of up to 1 ton per hour.
  • Constant Cutting Circle (CCC) cutting radius.
  • Mineral-composite technology of the base, MKT. The base of the Rapid ThermoPro series is made of a special mineral-composite material to give the stability necessary for high-quality crushing and effective absorption of shocks and vibrations.

Description

Characteristics

Ask question

Integrated contour control

Thanks to the integrated contour control, the noise level is reduced below 80 dB (A) in most applications. The machine is equipped with an inspection window that allows the operator to easily detect problems with the feed.

External control loop

Suitable for in-line crushing of skeletal waste with non-perforated products. It can work with a mold depth of up to 80 mm depending on the material.

The loop control lever is installed in the front of the machine and is removable to facilitate maintenance and cleaning of the machine. It can be supplemented with loads to improve functionality.

Autonomous contour control

Suitable for products up to 200 mm and in the presence of non-perforated products in the frame. The loop can be supplemented with weights to improve functionality.

Autonomous contour control
Suitable for deep drawing of products with a diameter of up to 200 mm and in the presence of untreated products in the frame. The loop control lever can be supplemented with weights to improve functionality.
